Omron PCB Mount Power Relay, 12V dc Coil, 5A Switching Current, DPDT
Technical Document
Specifications
Brand
OmronCoil Voltage
12V dc
Contact Configuration
DPDT
Mounting Type
PCB Mount
Switching Current
5A
Number of Poles
2
Latching
No
Terminal Type
Through Hole
Length
29mm
Coil Resistance
275Ω
Depth
13mm
Contact Material
Silver
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
+70°C
Height
25.5mm
Series
G2R-2
Maximum Switching Power DC
150 W
Maximum Switching Power AC
1.25 kVA
Application
Power
Product details
G2R Series
General purpose PCB power relay used in various domestic and commercial applications
8mm creepage/clearance
H25.5 x W13 x D29 mm
Approvals
UL508; CSA22.2; EN 61810-1; SEV; SEMKO
