Recom RH DC-DC Converter, ±12V dc/ ±42mA Output, 21.6 → 26.4 V dc Input, 1W, Through Hole, +85°C Max Temp -40°C
Technical Document
Specifications
Brand
RecomOutput Voltage
±12V dc
Input Voltage Range
21.6 → 26.4 V dc
Power Rating
1W
Input Voltage Nominal
24 V dc
Output Current
±42mA
Mounting Type
Through Hole
Isolated
Yes
Number of Outputs
2
Package
SIP
Isolation Voltage
3kV dc
Depth
10.2mm
Length
19.6mm
Series
RH
Minimum Temperature
-40°C
Maximum Temperature
+85°C
Country of Origin
Taiwan, Province Of China
Product details
Recom 1W SIP Dual Output Medical Approved Unregulated Isolated DC-DC Converter - RH Series
The Recom RH Series DC/DC-Converter complements Recom’s industrial range of converters with very high isolations of 3KV and 4kVdc. These DC/DC converters feature an extended operating temperature range of –40°C to +90°C as standard. The converters are EN-60601-1 certified, making them suitable for medical as well as IGBT driver applications.
Unregulated outputs
Medical safety approval EN-60601-1
3kVdc isolation
Efficiency at full load up to 84%
Short circuit protection
UL94V-0 package material
SIP7 package
Standards
EN-60950-1, EN-60601-1
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
€ 15.67
€ 15.67 Each (Exc. VAT)
€ 18.49
€ 18.49 Each (inc. VAT)
1
€ 15.67
€ 15.67 Each (Exc. VAT)
€ 18.49
€ 18.49 Each (inc. VAT)
1
Stock information temporarily unavailable.
Please check again later.
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 15.67 |
| 5 - 9 | € 15.42 |
| 10 - 24 | € 15.16 |
| 25 - 49 | € 14.91 |
| 50+ | € 14.63 |
