TDK-Lambda Switching Power Supply, JWT75-522/A, 5 V dc, ±12 V dc, 4 A, 8 A, 500 mA, 75W, Triple Output, 120 →
Technical Document
Specifications
Brand
TDK-LambdaOutput Voltage
5 V dc, ±12 V dc
Output Current
4 A, 8 A, 500 mA
Power Rating
75W
Number of Outputs
3
Input Voltage
120 → 330 V dc, 85 → 265 V ac
Mounting Type
Chassis Mount
Package Type
Enclosed
Length
188mm
Width
92mm
Depth
42mm
Efficiency
72%
Maximum Temperature
+50°C
Minimum Temperature
-10°C
Weight
600g
Country of Origin
Malaysia
Product details
50-150W, Universal Input, Single/Triple O/P, JWS & JWT Series
Power factor correction on all units
Adjustable output voltage
EMC meets EN55011, EN55022-B, FCC-B, VCCI-B for conducted and radiated emission
Over voltage/overcurrent protection
Fully regulated output
Supplied complete with cover; (JWS50 de-rates to 60% @ 55°C, JWS75/100/150 de-rates to 60% @ 50°C)
Operating temperature range –10°C to 45°C (can be increased with the cover removed)
Approvals
TUV, UL Recognised Component for Canada & US
Standards
EN60950, UL1950
Stock information temporarily unavailable.
Please check again later.
€ 398.61
€ 398.61 Each (Exc. VAT)
€ 470.36
€ 470.36 Each (inc. VAT)
1
€ 398.61
€ 398.61 Each (Exc. VAT)
€ 470.36
€ 470.36 Each (inc. VAT)
1
Buy in bulk
| Quantity | Unit price |
|---|---|
| 1 - 4 | € 398.61 |
| 5 - 9 | € 394.23 |
| 10 - 24 | € 389.91 |
| 25 - 49 | € 386.16 |
| 50+ | € 382.50 |
