TE Connectivity PCB Mount Signal Relay, 5V dc Coil, 1A Switching Current, DPDT
Technical Document
Specifications
Brand
TE ConnectivityCoil Voltage
5V dc
Contact Configuration
DPDT
Mounting Type
PCB Mount
Maximum Switching Current DC
1 A
Maximum Switching Voltage AC
120V ac
Maximum Switching Voltage DC
30V dc
Series
G6S
Maximum Switching Power DC
60 W
Latching
No
Length
12.3mm
Depth
7.3mm
Height
9.2mm
Dimensions
12.3 x 9.9 x 7.4mm
Terminal Type
Through Hole
Number of Poles
1
Application
Compact
Switching Current
1A
Contact Material
Gold Plated
Maximum Operating Temperature
+80°C
Isolation Coil To Contact
2kV ac
Minimum Operating Temperature
-30°C
Coil Power
300mW
Maximum Switching Power AC
62.5VA
Coil Resistance
83Ω
Operating Temperature Range
-30 → +80°C
Features
2.54mm Terminal Pitch Same as I.C. Socket Terminal Pitch
Country of Origin
China
Product details
Signal Relay TSC Series
TSC Series of miniature PCB relays. Typical applications include: Telecommunications, office machines and security systems.
1A SPCO miniature relay
Contact material; AgNi, Au plated
Low coil power requirement for IC compatibility
Sealed plastic case
Nominal power: Standard coil 300mW; Sensitive coil 150mW T
